SER65011 - Double push button with battery
Product Description
The battery-powered double push-button is a battery-operated radio micro-transmitter that converts a local button press into a Bluetooth Mesh command.
Depending on the configuration chosen in the mobile App, each of the two buttons can control lighting (On/Off, dimming), a shutter (1 or 2 buttons), a chime, or trigger a scenario.
Integrated into Bluetooth Mesh in Low Power mode, it also includes the range’s general functions: status LEDs, Reset button, wake-up via button combination, battery management, software update via the app, and integration with Vigilant Home.
Item code : SER65011
Internal ref. : REF27
Technical Specifications
Power supply: CR2430 non-rechargeable battery
Connectivity: Bluetooth Mesh (Low Power Node)
Dimensions: To be completed
Operating temperature: 10°C - 60°C
Mounting: Wall-mounted button, free-standing or behind an existing fixture
Supported Functions
Control
Automation
Vigilant Home · Scenario management
Security
Standard range functions
Product interfaces · Power supplies · Product health indication · User account · Software updates · Bluetooth Mesh connectivity functions
Electrical Installation
Interfaces
Powering up and connecting I/Os
Input wiring 2-button/rocker switch
If the switch is a push button, you can choose an assignment for the input from the following list:
Lighting and socket management - On/Off switch (1 button required)- Lighting and socket management - Dimmer push-button (1 button required)
Doorbell and chime - Doorbell and chime (1 button required)
Shutter management - Shutter switches (1 button required)- Shutter management - Shutter switches (2 buttons required)
Scenario management - Scenario trigger button (1 button required)
Functional Setup
Once the product is electrically installed, you can power it on.
You can then start the functional setup from the mobile App.
Revision date : Oct 13, 2026
